A3968SLB-T 技术资料
A3968SLB-T.pdf询价热线：
0755－83283733, 83031813，33062500
QQ：623069669
MSN：sumzi003@sumzi.com sumzi006@sumzi.com
Email:sumzi@sumzi.com
■ ±650 mA Continuous Output Current■ 30 V Output Voltage Rating
■ Internal Fixed-Frequency PWM Current Control
■ Satlington Sink Drivers
■ Brake Mode
■ User-Selectable Blanking Window
■ Internal Ground-Clamp & Flyback Diodes
■ Internal Thermal-Shutdown Circuitry
■ Crossover-Current Protection and UVLO Protection
ABSOLUTE MAXIMUM RATINGS
Load Supply Voltage, VBB ................... 30 V
Output Current, IOUT (peak) .......... ±750 mA
(continuous) .............................. ±650 mA
Logic Supply Voltage, VCC ................. 7.0 V
Input Voltage, Vin ..... -0.3 V to VCC + 0.3 V
Sense Voltage, VS ................................ 1.0 V
Package Power Dissipation (TA = 25°C), PD
A3968SA ..................................... 1.8 W*
A3968SLB ................................... 1.4 W*
Operating Temperature Range,
TA ................................... -20°C to +85°C
Junction Temperature,
TJ ................................................. +150°C
Storage Temperature Range,
TS ................................. -55°C to +150°C
