【产品名称】k6x4008c1f-bf55
【产品类别】静态储存器
【产品封装】SOP-32
【生产厂家】SAMSUNG
【产品批号】 06+ROHS
【产品价格】 欢迎来电洽谈！
(点击可下载PDF技术资料)
512Kx8 bit Low Power full CMOS Static RAM
FEATURES
· Process Technology: Full CMOS
· Organization: 512Kx8
· Power Supply Voltage: 4.5~5.5V
· Low Data Retention Voltage: 2V(Min)
· Three state output and TTL compatible
· Package Type: 32-DIP-600, 32-SOP-525,
32-TSOP2-400F/R
· Process Technology: Full CMOS
· Organization: 512Kx8
· Power Supply Voltage: 4.5~5.5V
· Low Data Retention Voltage: 2V(Min)
· Three state output and TTL compatible
· Package Type: 32-DIP-600, 32-SOP-525,
32-TSOP2-400F/R
GENERAL DESCRIPTION
The K6X4008C1F families are fabricated by SAMSUNG¢s
advanced full CMOS process technology. The families supports
various operating temperature range and various
package types for user flexibility of system design. The families
also support low data retention voltage for battery backup
operation with low data retention current.
advanced full CMOS process technology. The families supports
various operating temperature range and various
package types for user flexibility of system design. The families
also support low data retention voltage for battery backup
operation with low data retention current.
