A3212 最小封装型号为 A3212EELL 全极性霍尔开关
Description：
print
tel：0755-83031813
email：sumzi@sumzi.com
- Production
- Technology
- Configuration
- Download
Production：
A3212EEHLT-T 型号
A3212EEHLT-T 类型 微功耗超灵敏
A3212EEHLT-T 应用
ALLEGRO 品牌系列产品
A3212EEHLT-T 批号
A3212EEHLT-T 数量
A3212EEHLT-T 封装
A3212EEHLT-T 包装 3000PCS/REEL
A3212EEHLT-T 价格
A3212EEHLT-T 备注 原装正品，无铅
A3212EEHLT-T 技术资料(点击型号PDF文档下载)
A3212EEHLT-T 相关型号 A3212EELL(可订货，四周到货，3K起订)
询价热线：
0755－83283733, 83031813，33062500
QQ：623069669
MSN：sumzi003@sumzi.com sumzi006@sumzi.com
Email:sumzi@sumzi.com
http://www.sumzi.com
Features and Benefits
▪ Micropower operation
▪ Operation with north or south pole
▪ 2.5 to 3.5 V battery operation
▪ Chopper stabilized
▫ Superior temperature stability
▫ Extremely low switchpoint drift
▫ Insensitive to physical stress
▪ High ESD protection
▪ Sol id-state reliability
▪ Small size
▪ Easily manufacturable with magnet pole independence
Description
The A 3211 and A3212 integrated circuits are ultra-sensitive,
pole in de pen dent Hall-effect switches with latched digital
output. These sensors are es pe cial ly suited for operation in
battery-operated, hand-held equip ment such as cellular and
cordless tele phones, pagers, and palmtop com put ers. A 2.5
volt to 3.5 volt operation and a unique clocking scheme reduce
the average op er at ing power requirements to less than 15 μW
with a 2.75 volt supply.
Unlike other Hall-effect switches, either a north or south pole
of suf fi cient strength will turn the output on in the A3212,
and in the absence of a magnetic field, the output is off. The
A3211 provides an inverted output. The polarity independence
and minimal power requirements allow these devices to easily
replace reed switches for superior reliability and ease of
manufacturing, while eliminating the requirement for signal
conditioning.
Improved stability is made possible through chopper
stabilization (dynamic offset cancellation), which reduces the
residual offset voltage normally caused by device overmolding,
temperature de pen den cies, and thermal stress.
