Production：
【Part No.】 FAN8200MTCX【Category】 Low Saturation Stepping Motor Driver
【Packing】 14-Lead TSSOP
【MFQ】 Fairchild
【Datasheet】 FAN8200MTCX Datasheet
Description
The FAN8200/FAN8200D/FAN8200MTC/FAN8200MP is a
monolithic intergrated circuit designed for two-phase stepping
motor drive systems. It has dual H-bridge drivers with
vertical-PNP power transistors. Each of the bridges has an
independant enable pin, therefore it can be used for other
applications as well as stepping motor drive systems.
Features
• 3.3V and 5V MPU interface
• Dual H-bridge drivers for bipolar stepping motor drives
• Built-in vertical-PNP power transistors
• Wide supply voltage range (VCC = 2.5V ~ 7.0V)
• Low saturation voltage (0.4V@ 0.4A)
• Built-in chip enable function for each bridge
• Built-in shoot-through current protection
• Built-in thermal shutdown(TSD) function
