Production£º

AH180 is comprised of two Hall effect plates and an open-drain output driver, mainly designed for battery-operation, hand-held equipment (such as Cellular and Cordless Phone, PDA). The total power consumption in normal operation is typically 24¦ÌW with a 3V power source. Either north or south pole of sufficient strength will turn the output on. The output will be turned off under no magnetic field. While the magnetic flux density (B) is larger than operating point (Bop), the output will be turned on (low), the output is held until B is lower than release point (Brp), then turned off.

Features

• Micropower operation
• Operation with magnetic field of either north or south pole (omnipolar)
• 2.5V to 5.5V battery operation
• Chopper stabilized
• Superior temperature stability
• Extremely Low Switch-Point Drift
• Insensitive to Physical Stress
• Good RF noise immunity
• -40¡ãC to 85¡ãC operating temperature
• SIP-3L/SC59/Low profile DFN2020-6, DFN2020-3 package
• ESD (HBM) £¾ 5KV for DFN2020-6, DFN2020-3
£¾ 6KV for SIP-3L and SC59
• Lead Free Package: SIP-3L (Note 1)
• SC59 (commonly known as SOT23 in Asia), DFN2020-6 and DFN2020-3: Available in ¡°Green¡± Molding Compound (No Br, Sb) (Note 2)
• Lead Free Finish/RoHS Compliant (Note 3)
