Allegro MicroSystems, Inc. Announces New BLDC Full-Bridge Motor Driver with Integrated Hall Commutation Small Package Outline with Low Profile

Worcester, MA ¨C January 21, 2009 ¡ª Allegro® announces a new full-bridge motor driver designed to drive low-voltage, brushless DC motors. Allegro¡¯s A1448 is designed to allow the user to control several functions with a single input control pin. The pin allows for direct input PWM for speed control, is used to initiate the active braking function to reduce motor stop time, and acts as an enable pin to engage micro-power sleep mode to reduce average power consumption when not in use. This new device is targeted at the communications and office automation markets. It is designed for use in vibration motor applications in portable devices that require fast stop start cycles, such as haptic applications and vibration ring tones.
download hi-res image

The integrated Hall sensor used to detect the rotational position of an alternating-pole ring magnet achieves motor commutation. A high density CMOS semiconductor process allows the integration of all the necessary electronics. This includes the Hall sensor, the motor control circuitry, and the full output bridge. Low-voltage design techniques have been employed to achieve full device functionality down to 1.8 V VDD.

This fully integrated single chip solution provides enhanced reliability (including reverse battery protection and output short circuit protection) and eliminates the need for any external support components. The A1448 also employs a soft-switching algorithm to reduce audible switching noise and EMI interference, making this device in BLDC motors superior to existing brush motor solutions.

A micro power sleep mode can be initiated on the CONTROL pin to reduce current consumption for battery management in portable electronic devices. This feature allows for the removal of a FET transistor for switching the device on and off.

Allegro¡¯s DFN (EW) package is the thinnest in the industry with a 0.4 mm maximum thickness that allows for very thin BLDC coin motor designs. The small package outline and low profile make this device ideally suited for use in applications where printed circuit board area and component headroom are at a premium. The A1448 is available in a lead (Pb) free, 6-pin DFN micro-leadframe package, with an exposed pad for enhanced thermal dissipation.

About Allegro

Allegro MicroSystems, Inc. is a leader in developing, manufacturing and marketing high-performance power integrated circuits and integrated Hall-effect magnetic sensors. Allegro¡¯s innovative solutions serve high-growth applications within the automotive, communications, computer/office automation, consumer and industrial markets. Allegro is headquartered in Worcester, Massachusetts (USA) with design and applications centers located in North and South America, Asia, and Europe. Further information about Allegro can be found at www.allegromicro.com.
