【产品名称】A3240LLHLT
【产品类别】 霍尔传感器
【产品应用】 精密开关霍尔效应
【产品封装】3-lead SOT
【生产厂家】ALLEGRO
【产品包装】3000PCS/REEL
【产品批号】 06+ROHS（无铅 环保）
【产品价格】 欢迎来电洽谈！
【技术参数】
(点击可下载PDF技术资料)
【产品说明】
CHOPPER-STABILIZED, PRECISION
HALL-EF FECT SWITCH
HALL-EF FECT SWITCH
ABSOLUTE MAXIMUM RATINGS
at TA = +25°C
Supply Voltage, VCC .......................... 26.5 V
Reverse Battery Voltage, VRCC .......... -30 V
Magnetic Flux Density, B ............ Unlimited
Output OFF Voltage, VOUT .................. 26 V
Continuous Output Current,
IOUT ......................................... 25 mA*
Reverse Output Current, IOUT ......... -50 mA
Package Power Dissipation, PD See Graph
Junction Temperature, TJ ................ +165°C
Operating Temperature Range, TA
Range ‘E’ ..................... -40°C to +85°C
Range ‘L’.................... -40°C to +150°C
Storage Temperature Range,
TS .............................. -65°C to +170°C
*Internal current limiting is intended to protect
the device from output short circuits.
Reverse Battery Voltage, VRCC .......... -30 V
Magnetic Flux Density, B ............ Unlimited
Output OFF Voltage, VOUT .................. 26 V
Continuous Output Current,
IOUT ......................................... 25 mA*
Reverse Output Current, IOUT ......... -50 mA
Package Power Dissipation, PD See Graph
Junction Temperature, TJ ................ +165°C
Operating Temperature Range, TA
Range ‘E’ ..................... -40°C to +85°C
Range ‘L’.................... -40°C to +150°C
Storage Temperature Range,
TS .............................. -65°C to +170°C
*Internal current limiting is intended to protect
the device from output short circuits.
