当前位置：甩卖价出售 AT24C512N-10SU-2.7原装现货 提供报价及技术参数 0755－83283733王小姐
发布时间：2009-04-09 浏览：5012次
【产品型号】AT24C512N-10SU-2.7
【产品类型】Two-wire Serial EEPROM（记忆器）
【产品规格】8-lead SOIC
【生产厂家】ATMEL
【产品说明】全新原装现货，06、07年无铅，ATMEL特约经销商，详情欢迎来电咨询！
Features：
• Low-voltage and Standard-voltage Operation
– 2.7 (VCC = 2.7V to 5.5V)
– 1.8 (VCC = 1.8V to 3.6V)
• Internally Organized 65,536 x 8
• Two-wire Serial Interface
• Schmitt Triggers, Filtered Inputs for Noise Suppression
• Bidirectional Data Transfer Protocol
• 1 MHz (5V), 400 kHz (2.7V) and 100 kHz (1.8V) Compatibility
• Write Protect Pin for Hardware and Software Data Protection
• 128-byte Page Write Mode (Partial Page Writes Allowed)
• Self-timed Write Cycle (5 ms Max)
• High Reliability
– Endurance: 100,000 Write Cycles
– Data Retention: 40 Years
• Automotive Devices Available
• 8-lead PDIP, 8-lead EIAJ SOIC, 8-lead JEDEC SOIC, 8-lead TSSOP,
8-lead LAP, 8-lead SAP and 8-ball dBGA2 Packages
• Die Sales: Wafer Form, Waffle Pack and Bumped Die
• Low-voltage and Standard-voltage Operation
– 2.7 (VCC = 2.7V to 5.5V)
– 1.8 (VCC = 1.8V to 3.6V)
• Internally Organized 65,536 x 8
• Two-wire Serial Interface
• Schmitt Triggers, Filtered Inputs for Noise Suppression
• Bidirectional Data Transfer Protocol
• 1 MHz (5V), 400 kHz (2.7V) and 100 kHz (1.8V) Compatibility
• Write Protect Pin for Hardware and Software Data Protection
• 128-byte Page Write Mode (Partial Page Writes Allowed)
• Self-timed Write Cycle (5 ms Max)
• High Reliability
– Endurance: 100,000 Write Cycles
– Data Retention: 40 Years
• Automotive Devices Available
• 8-lead PDIP, 8-lead EIAJ SOIC, 8-lead JEDEC SOIC, 8-lead TSSOP,
8-lead LAP, 8-lead SAP and 8-ball dBGA2 Packages
• Die Sales: Wafer Form, Waffle Pack and Bumped Die
Description：
The AT24C512 provides 524,288 bits of serial electrically erasable and programmable
read only memory (EEPROM) organized as 65,536 words of 8 bits each. The device’s
cascadable feature allows up to four devices to share a common two-wire bus. The
device is optimized for use in many industrial and commercial applications where lowpower
and low-voltage operation are essential. The devices are available in spacesaving
8-pin PDIP, 8-lead EIAJ SOIC, 8-lead JEDEC SOIC, 8-lead TSSOP, 8-lead
Leadless Array (LAP), and 8-lead SAP packages. In addition, the entire family is available
in 2.7V (2.7V to 5.5V) and 1.8V (1.8V to 3.6V) versions.
The AT24C512 provides 524,288 bits of serial electrically erasable and programmable
read only memory (EEPROM) organized as 65,536 words of 8 bits each. The device’s
cascadable feature allows up to four devices to share a common two-wire bus. The
device is optimized for use in many industrial and commercial applications where lowpower
and low-voltage operation are essential. The devices are available in spacesaving
8-pin PDIP, 8-lead EIAJ SOIC, 8-lead JEDEC SOIC, 8-lead TSSOP, 8-lead
Leadless Array (LAP), and 8-lead SAP packages. In addition, the entire family is available
in 2.7V (2.7V to 5.5V) and 1.8V (1.8V to 3.6V) versions.
