TLE4913 型号
TLE4913 类型 低功耗霍尔效应开关
TLE4913 应用 霍尔效应芯片开关的功耗仅10mW，最低供电电压为2.4V，具有全方向磁性切换功能，可用于手机、小灵通、无线电话或个人数字助理(PDA)等合盖开关检测的电池供电设备
TLE4913 批号 06+ROHS
TLE4913 数量 大量现货
TLE4913 封装 SC59/SOT-23
TLE4913 包装 3000PCS/盘
TLE4913 厂家 英飞凌(Infineon）
TLE4913 备注 TLE4913低功耗霍尔效应开关，全新原装现货，拥有大量库存现货，可提供图片及样品作为参考，详情欢迎来电咨询！！！
请点击红色字体下载或查看：
TLE4913 技术参数.pdf
TLE4913 报价 请直接与我电话联系：0755-83031813/王小姐
Features
• Micro power design
• 2.4 V to 5.5 V battery operation
• High sensitivity and high stability of the
magnetic switching points
• High resistance to mechanical stress
• Digital output signal
• Switching for both poles of a magnet (omnipolar)
Functional Description
The TLE4913 is an Integrated Hall-Effect Sensor designed specifically to meet the
requirements of low-power devices. e.g. as an On/Off switch in Cellular Flip-Phones, with
battery operating voltages of 2.4V – 5.5V.
Precise magnetic switching points and high temperature stability are achieved through the
unique design of the internal circuit.
An onboard clock scheme is used to reduce the average operating current of the IC.
During the operate phase the IC compares the actual magnetic field detected with the
internally compensated switching points. The output Q is switched at the end of each
operating phase.
During the Stand-by phase the output stage is latched and the current consumption of the
device reduced to some µA.
The IC switching behaviour is Omnipolar, i.e. it can be switched on with either the North or
South pole of a magnet.
