当前位置：A3213EUA 微功率、超灵敏霍尔效应开关
发布时间：2009-03-07 浏览：4548次
A3213EUA 销售专线:0755-33062500
A3213EUA 类型 微功率、超灵敏霍尔效应开关
A3213EUA 类型 微功率、超灵敏霍尔效应开关
A3213EUA 包装
A3213EUA 价格
A3213EUA 备注 原装正品 现货热卖 最新到货
A3213EUA 技术资料(点击型号PDF文档下载)
A3213EUA 相关型号 A1106EUA-T A1106ELHLT-T A1104EU-T A1104EUA-T A1102LUA-T
A3213EUA 备注 原装正品 现货热卖 最新到货
A3213EUA 技术资料(点击型号PDF文档下载)
A3213EUA 相关型号 A1106EUA-T A1106ELHLT-T A1104EU-T A1104EUA-T A1102LUA-T
FEATURES
■ Micropower Operation
■ Operate With North or South Pole
■ 2.4 V to 5.5 V Battery Operation
■ Chopper Stabilized
Superior Temperature Stability
Extremely Low Switch-Point Drift
Insensitive to Physical Stress
■ ESD Protected to 5 kV
■ Sol id-State Reliability
■ Small Size
■ Easily Manufacturable With Magnet Pole Independence
■ Micropower Operation
■ Operate With North or South Pole
■ 2.4 V to 5.5 V Battery Operation
■ Chopper Stabilized
Superior Temperature Stability
Extremely Low Switch-Point Drift
Insensitive to Physical Stress
■ ESD Protected to 5 kV
■ Sol id-State Reliability
■ Small Size
■ Easily Manufacturable With Magnet Pole Independence
ABSOLUTE MAXIMUM RATINGS
at TA = +25°C
Supply Voltage, VDD .............................. 6 V
Magnetic Flux Density, B .......... Unlimited
Output Off Voltage, VOUT ...................... 6 V
Output Current, IOUT ........................... 1 mA
Junction Temperature, TJ ................ +170°C
Operating Temperature Range, TA
Suffix 'E' ...................... -40°C to +85°C
Suffix 'L' ................... -40°C to +150°C
Storage Temperature Range,
TS .............................. -65°C to +170°C
Caution: These CMOS devices have input
static protection (Class 3) but are still susceptible
to damage if exposed to extremely
high static electrical charges.
at TA = +25°C
Supply Voltage, VDD .............................. 6 V
Magnetic Flux Density, B .......... Unlimited
Output Off Voltage, VOUT ...................... 6 V
Output Current, IOUT ........................... 1 mA
Junction Temperature, TJ ................ +170°C
Operating Temperature Range, TA
Suffix 'E' ...................... -40°C to +85°C
Suffix 'L' ................... -40°C to +150°C
Storage Temperature Range,
TS .............................. -65°C to +170°C
Caution: These CMOS devices have input
static protection (Class 3) but are still susceptible
to damage if exposed to extremely
high static electrical charges.
