The LTC6081/LTC6082 CMOS operational amplifiers offer a 3.5-MHz gain bandwidth and less than 90-µV offset over the entire -40¡ã to 125¡ãC temperature range. Featuring rail-to-rail input and output stages, the dual LTC6081 and quad LTC6082 achieve a frequency noise of just 1.3 µVp-p and an input bias current of 1 pA max at 25¡ãC.

The parts consume 330 µA per amplifier and offer an optional shutdown feature, allowing the current to be reduced to 0.5 µA per amplifier. In addition, the amplifiers have a slew rate of 1 V/µs, a CMRR of 105 dB, and a PSSR of 90 dB.
